Using the enhanced strategies, any number of surfaces are permitted for the suction and pressure sides, making it exceptionally easy to extend blade surfaces. No longer do blade surfaces need to be ruled for accurate programming results. For optimal high precision machining, hyperMILL “High Precision Surface Mode” and “Smooth Overlap” strategies can also be applied when using 5-axis Radial Machining, ensuring the best surface quality and clean transitions.įor high-quality surface finishes and to simplify programming when flank and point milling blades, hyperMILL 2021.1 offers several enhanced Multi-Blade strategies.
Using a new radial projection method, toolpaths are calculated quickly so that the most productive machining strategies can be applied. To streamline access to Product Manufacturing Information (PMI) and metadata, hyperMILL 2021.1 offers a new import function that retrieves face quality information and metadata when importing CAD data from neutral or native formats, and attaches data to the imported faces in hyperCAD-S, making the information available to hyperMILL and its machining processes.Ī new 5-axis Radial Machining strategy allows bottle shapes and similar cavities to be easily and efficiently programmed in hyperMILL, resulting in high-quality surface finishes. Especially productive for optimizing tool and mold making, the new toolpath editing feature is easy-to-use, and offers programmers the flexibility to adapt toolpaths by trimming and removing sequences accordingly for component conditions. Key innovations include a new “Interactive Edit Toolpath” capability which enables toolpath editing after initial toolpath generation.
Hypermill solidworks software#
OPEN MIND Technologies AG, a leading developer of CAD/CAM software solutions, has introduced its latest hyperMILL 2021.1 CAD/CAM software suite which offers users new and enhanced features for efficient 3D, 5-axis and mill/turn machining.
